Tool Revolution
Pipe Airtightness Test
Anchor Setting Tool
We create innovative tools.
Offering innovative pipe sealing solutions for easy airtightness tests
Enables Anchor Installation Without Rotation
Leading the Blue Ocean of K-Tools with Patented Solutions
We Listen to the Field
Pipe Airtightness Test
Pipe End Sealing
Push-to-Seal Technology
Integrated Inlet and Pressure Gauge
Easy Installation and Removal
Reusable
Anchor Setting Tool
Rotation-Free Connection
Easy Attachment and Detachment
Easy Installation
Semi-Permanent Durability
Pipe Airtightness Test
User Manual
Pipe Airtightness Test
Insert the cylinder into the rubber and screw the adjustment plate onto the cylinder's threads.
1.Place the adjustment plate at the beginning of the cylinder's threads and pull the rubber toward the plate to separate it from the cylinder, allowing the rubber to move freely.
2.Insert the product into the pipe end and rotate the adjustment plate; as the cylinder is pulled, the rubber expands along the slope and tightly seals against the pipe.
3.Insert the product with an inlet at the specified end, inject air using an atomizer, and check the pressure.
4.After use, rotate the adjustment plate in the opposite direction and push it forward; this separates the cylinder from the rubber, causing the rubber to contract so the product can be easily retrieved from the pipe.
5.The retrieved product is reusable.
Anchor Setting Tool
User Manual
Anchor Setting Tool
The anchor can be installed simply by insertion without rotational coupling by using the anchor installation tool.
When an anchor is inserted into a general tool and struck with a hammer, the impact force usually causes the tool to dislodge from the anchor; however, this product features a highly flexible structure to prevent such separation.
1.Connect the unit with the all-thread rod.
2.Insert the anchor into the top of the product.
3.When you push the anchor into the hole, the unit compresses, bringing the main body into direct contact
4.Install the anchor and remove the product without any rotation.
5.Upon completion, detach the unit from the threaded rod; it is designed for repeated reuse.
Tel +82-31-298-5300
207, Seosuwon-ro 594beon-gil, Gwonseon-gu, Suwon-si, Gyeonggi-do, Republic of Korea
[Product Inquiry] easilytech@nate.com
